GKS FLOW

Machine is standard equipped with:
EHEDG; stainless steel; hygienic design. Lenze PLC with 15,4” full color touchscreen. Film transport by means of vacuum, servo driven, pull belts. Film cut and splice table. Automatic lateral film adjustment. Photocell for bag length detection with pre-printed film. End of film detection. Pneumatic opening and closing of the servo driven film pull belts. Ergonomic film support with motorized drive and pneumatically locked axle. Low power and air consumption. Cover plate over the entire machine

Options: FLOW
QC-Seal system (LDPE, PP + Laminated films)
Air cooling on sealing system
Euroloch or handgrip sealing system
Block bottom/gusset mechanism
Lateral film guiding system
Vibration unit
Bag support system
Connection for gas flushing (MAP)
Perforation systems
Printing and labeling systems
Various weighing and dosing systems
Customer specific options on request

Technical specifications FLOW
Bag width (pillow) 80 – 350 mm
Max. bag length unlimited mm
Max. production speed 200 bpm
Film thickness 25 – 130 μ
Core diameter 76 (3”) mm
Max. film width 800 mm
Max. outer diameter film roll 600 mm
Power during production ca. 1.800 Watt
Voltage 400 Volt/50 Hz/16 A
All dimensions and specifications are indications based on standard set up. Final details depend on customer specification
